IPC-HFW2300R-VF
Lite series




1/3” 3Megapixel progressive CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@3M(2048x1536) &25/30fps@1080P(1920 x1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.7~12mm varifocal lens
Max IR LEDs Length 30m
IP66
0.01Lux/F1.4 (Color), 0Lux/F1.4(IR on)
Angle of View H: H: 92°~ 28°
Lens Type: Manual/ Fixed Iris
DC12V/PoE (802.3af)
-30°C~+60°C, Less than 95% RH
Power Consumption < 4.5W


IPC-HFW2320R-ZS
Lite series




1/3” 3Megapixel progressive CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@3M(2304x1296) (2048x1536) &25/30fps@1080P(1920 x1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.7~12mm varifocal lens
Max IR LEDs Length 30m
IP67,Micro SD card slot, up to 128GB
0.01Lux/F1.4 (Color), 0Lux/F1.4(IR on)
Angle of View H: H: 92°~ 28°
Lens Type: Motorized/ Fixed Iris
DC12V/PoE (802.3af)
-30°C~+60°C, Less than 95% RH
Power Consumption < 8.5W


http://www.dahuasecurity.com



IPC-HFW1200S
Lite series




1/3” 3Megapixel progressive scan CMOS
H.264&MJPEG dual-stream encoding
Max 25/30fps@1080P(1920x1080)/720P(1280x720)
Day/Night(ICR), 2DNR,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm optional)
Max. IR LEDs Length 30m
IP66
0.1Lux/F1.6 (Color) ;0Lux/F1.6(IR on)
Angle of View H: H: 72.5°(44°)
Lens Type: Fixed lens
DC12V,PoE (802.3af)
-30°C~+60°C, Less than 95% RH
Power Consumption Max 6W


IPC-HFW1220S
Lite series




1/2.7” 2Megapixel progressive scan CMOS
H.264&MJPEG dual-stream encoding
25/30fps@1080P(1920x1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm optional)
Max. IR LEDs Length 30m
IP67
0. 025Lux/F2.1(Color), 0Lux/F2.1(IR on)
Angle of View H: H: 93°(63°)
Lens Type: Fixed lens
DC12V,PoE (802.3af)
-30°C~+60°C, Less than 95% RH
Power Consumption <5.5W(IR on)


http://www.dahuasecurity.com



IPC-HFW1300S
Lite series




1/3” 3Megapixel progressive scan CMOS
H.264&MJPEG dual-stream encoding
Max 20fps@3M(2048×1536)&25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR),AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm optional)
Max. IR LEDs Length 30m
IP66
0.1Lux/F1.6 (Color) ;0Lux/F1.6(IR on)
Angle of View H: H: 71.9°(45.3°)
Lens Type: Fixed lens
DC12V,PoE (802.3af)
-30°C~+60°C, Less than 95% RH
Power Consumption Max 6W


IPC-HFW1320RM
Lite series




1/3” 3Megapixel progressive scan CMOS
H.264&MJPEG dual-stream encoding
Max 20fps@3M(2048×1536)&25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC,
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm optional)
Max. IR LEDs Length 20m
IP67
0. 045Lux/F2.1(Color), 0Lux/F2.1(IR on)
Angle of View H: H: 81°(55°)
Lens Type: Fixed lens
DC12V,PoE (802.3af)
-30°C~+60°C, Less than 95% RH
Power Consumption <3.7W(IR on)


http://www.dahuasecurity.com



IPC-HFW4300E
Eco-savvy series




1/3” 3Megapixel progressive scan Aptina CMOS
H.264 &MJPEG dual-stream encoding
Max 20fps@3M(2048×1536)&25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm,8mm optional)
Max. IR LEDs Length 30m
IP66
0.01Lux/F1.6 (Color),0Lux/F1.6(IR on)
Angle of View H:72.5°(44°/33.2°)
Lens Type: Fixed lens
DC12V, PoE (802.3af)
-20°C~+60°C, Less than 95% RH
Power Consumption < 5.5W


IPC-HFW5421E-Z
Eco-savvy 2.0 series




1/3” 4Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@4M(2688×1520), 25/30fps@3M(2304×1296),
WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC, HLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.7mm~12mm Motorized / Auto Iris(DC) lens
Max. IR LEDs Length 50m
IP67, Micro SD memory, Audio input
0.01Lux/F1.4(Color); 0Lux/F1.4(IR on)
Angle of View H: 100°~33°
DC12V, PoE(802.3af)
-40°C~+60°C,Less than 95% RH
Power Consumption <11.5W(with IR on, motorized lens working)


http://www.dahuasecurity.com



IPC-HDBW2300R-VF
Lite series





1/3” 3Megapixel progressive CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@3M(2048x1536) &25/30fps@1080P(1920 x1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.7~12mm varifocal lens
Max IR LEDs Length 30m
IP66, IK10
0. 01Lux/F1.4 (Color), 0Lux/F1.4(IR on)
Angle of View H: H: 92°~ 28°
Lens Type: Manual/ Fixed Iris
DC12V/PoE (802.3af)
-30°C~+60°C, Less than 95% RH
Power Consumption < 4.5W


IPC-HDBW2201R-ZS
Lite series




1/3” 2Megapixel progressive scan Aptina CMOS
H.264 & MJPEG dual-stream encoding
25/30fps@1080P(1920x1080) & 25/30fps@720P(1280×720)
Day/Night(ICR), 3DNR, AWB, AGC, BLC, WDR(120dB)
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.7~12mm varifocal lens
Max IR LEDs Length 20m
IP66, IK10, Micro SD Memory Slot
0. 01Lux/F1.4 (Color), 0Lux/F1.4(IR on)
Angle of View H: H: 82°～28°
Lens Type: Motorized/Fixed Iris
DC12V/PoE (802.3af)
-30°C~+60°C, Less than 95% RH
Power Consumption < 7.5W


http://www.dahuasecurity.com



IPC-HDBW2200E-V2
Lite series




1/3” 3Megapixel progressive scan Aptina CMOS
H.264 & MJPEG dual-stream encoding
Max 25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (2.8mm, 6mm optional)
Max. IR LEDs Length 30m
IP66, IK10
Color: 0.1Lux/F1.6; 0Lux (IR on)
Angle of View H: 71.9°(90°/45°)
Lens Type: Fixed lens
DC12V, PoE(802.3af)
-30°C~+60°C,Less than 95% RH
Power Consumption < 4,5W


IPC-HDW1220S
Lite series




1/2.7” 2Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
25/30fps@2M(1920×1080)
DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC,HLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm optional)
Max. IR LEDs Length 30m
IP67
0. 025Lux/F2.1(Color), 0Lux/F2.1(IR on)
Angle of View H: 93°(63°)
Lens Type: Fixed lens
DC12V, PoE(802.3af)
-30°C~+60°C,Less than 95% RH
Power Consumption <4.4W(IR on)


http://www.dahuasecurity.com



IPC-HDW1320S
Lite series




1/3” 3Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@3M(2048×1536) & 25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC,HLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8mm fixed lens (3.6mm, 6mm optional)
Max. IR LEDs Length 30m
IP67
0. 045Lux/F2.1(Color), 0Lux/F2.1(IR on)
Angle of View H: 92°(81°,55°)
Lens Type: Fixed lens
DC12V, PoE(802.3af)
-30°C~+60°C,Less than 95% RH
Power Consumption <3.7W(IR on)


IPC-HDBW1320E
Lite series




1/3” 3Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@3M(2048x1536) (2304×1296)&25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC,HLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8mm fixed lens (3.6mm optional)
Max. IR LEDs Length 30m
IP67, IK10
0. 1Lux/F2.0(Color), 0Lux/F2.0(IR on)
Angle of View H: 92°(81°)
Lens Type: Fixed lens
DC12V, PoE(802.3af)
-30°C~+60°C,Less than 95% RH
Power Consumption <4W(IR on)


http://www.dahuasecurity.com



IPC-HDBW4421E
Eco-savvy 2.0 series




1/3” 4Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@4M(2688×1520), 25/30fps@3M(2304×1296),
WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC, HLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (2.8mm, 6mm optional)
Max. IR LEDs Length 30m
IP67, IK10
0.01Lux/F2.0 Color), 0Lux/F2.0(IR on)
Angle of View H: 84°(106°/56°)
DC12V, PoE(802.3af)
-30°C~+60°C,Less than 95% RH
Power Consumption Max 4W


IPC-HDBW4421E-AS
Eco-savvy 2.0 series




1/3” 4Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@4M(2688×1520), 25/30fps@3M(2304×1296),
WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC, HLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (2.8mm, 6mm optional)
Max. IR LEDs Length 30m
IP67, IK10, Micro SD memory, Audio input
0.01Lux/F2.0 Color), 0Lux/F2.0(IR on)
Angle of View H: 84°(106°/56°)
DC12V, PoE(802.3af)
-30°C~+60°C,Less than 95% RH
Power Consumption Max 4W


http://www.dahuasecurity.com



IPC-HDB4200C
Eco-savvy series




1/2.8” 2Megapixel progressive scan Exmor CMOS
H.264 & MJPEG dual-stream encoding
Max 25/30fps@1080P(1920×1080)
DWDR,Day/Night(Electronic), 3DNR,Auto iris,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8mm fixed lens (3.6mm,6mm optional)
Backlight Compensation Off/BLC/HLC/DWDR
IP66, IK10, Micro SD memory
0.1 lux/F1.2(color)
Angle of View H: 110°(88°/53°)
Lens Type: Manual/Auto Iris (DC)
DC12V/PoE
-20°C~+60°C,Less than 95% RH
Power Consumption Max 3W


IPC-HDBW4200E-AS
Eco-savvy series




1/2.8” 2Megapixel progressive scan Exmor CMOS
H.264 & MJPEG dual-stream encoding
Max 25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.8mm fixed lens (3.6mm, 6mm optional)
Max. IR LEDs Length 30m
IP66, IK10, Micro SD memory, Audio input
0.1Lux/F1.8(Color), 0.01Lux/F1.8(B/W)
Angle of View H: 90°(72.5°/44°)
Lens Type: Fixed lens
DC12V, PoE(802.3af)
-20°C~+60°C,Less than 95% RH
Power Consumption Max 4W


http://www.dahuasecurity.com



IPC-HDBW5421E-Z
Eco-savvy 2.0 series




1/3” 4Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@4M(2688×1520), 25/30fps@3M(2304×1296),
WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC, HLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.7mm~12mm Motorized / Auto Iris(DC) lens
Max. IR LEDs Length 50m
IP67, IK10, Micro SD memory, Audio input
0.01Lux/F1.4(Color); 0Lux/F1.4(IR on)
Angle of View H: 100°~33°
DC12V, PoE(802.3af)
-30°C~+60°C,Less than 95% RH
Power Consumption Max 10W



http://www.dahuasecurity.com



IPC-HF5421E
Eco-savvy 2.0 series




1/3” 4Megapixel progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@4M(2688×1520), 25/30fps@3M(2304×1296),
WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC, HLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
C/CS mount for lense
Auto Iris
Micro SD memory, Audio input
0.01Lux/F1.2 (Color), 0.001Lux/F1.2(B/W)
Auto back focus(ABF)
DC12V/AC24V, PoE (802.3af)
Power Consumption <10W (ABF&ICR on)



http://www.dahuasecurity.com



SD6583A-HN





1/3” Exmor CMOS
H.264 & MJPEG dual-stream encoding
Max. 15fps@3Mp, 25/30fps@1080p resolution
WDR, Day/Night(ICR), DNR (2D&3D),Auto iris, Auto focus, AWB, AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Powerful 20x optical zoom
IK10 (optional)
IP67
Color: 0.05Lux@F1.6,B/W: 0.005Lux@F1.6
Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
Micro SD memory, Audio input
AC 24V/3A (±10%)
-40ºC ~ 60ºC / Less than 90% RH
Power Consumption 15W, 40W(Heater on)


SD6C230S-HN
Eco-savvy series




1/2.8” Exmor CMOS
H.264 & MJPEG dual-stream encoding
Max. 25/30fps@1080P(1920x1080) & 50/60fps@720P resolution
DWDR, Day/Night(ICR), Ultra DNR, Auto iris, Auto focus
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
30x optical zoom
IR Distance up to 100m (2 near IR LED+ 4 far IR LED)
IP66
Color: 0.05Lux@F1.6; B/W: 0.005Lux@F1.6, 0Lux (IR on)
Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
Micro SD memory, Audio input
AC 24V/3A (±10%)
-40ºC ~ 60ºC / Less than 90% RH
Power Consumption 10.5W, 26W (IR on, Heater on)


http://www.dahuasecurity.com



SD6582C-HN





1/3” Exmor CMOS
H.264 & MJPEG dual-stream encoding
Max 25/30fps@1080p resolution
Defog, DWDR, Day/Night(ICR), DNR (2D&3D),Auto iris, Auto focus, AWB, AGC,BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Powerful 30x optical zoom(4.3mm~129mm)
IK10 (optional)
IP67
Color: 0.05Lux@F1.6, B/W: 0.005Lux@F1.6
Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
Built-in 7/2 alarm in/out, Micro SD memory
AC 24V/3A (±10%)
-40ºC ~ 60ºC / Less than 90% RH
Power Consumption 15W, 40W(Heater on)



http://www.dahuasecurity.com




AV1115DN



New MegaVideo Compact series 1,3 Megapixel IP Camera
42 fps @ 1280(H) x 1024(V)
Color mode: 0.1 lux @ F1.4
CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max

AV3115DN
New MegaVideo Compact series 3 Megapixel IP Camera
21 fps @ 2048(H) x 1536(V)
Color mode: 0,1 lux in extended exposure mode or 0.3 lux @ F1.4
CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max

http://www.arecontvision.com




AV3105DN





3 Megapixel IP Camera
15 fps @ 2048(H)x1536 (V)
Color mode: 0,1 lux in extended exposure mode or 0.2 lux @ F1.4
1/2” CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max

AV3155DN
3 Megapixel IP Dome Camera
15 fps @ 2048(H)x1536 (V)
Integrated 4.5-10mm Megapixel Varifocal Lens
Color mode: 0,1 lux in extended exposure mode or 0.2 lux @ F1.4
1/2” CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max
IP66 dome housing
Camera gimbal with 360° pan and 90° tilt adjustment

http://www.arecontvision.com




AV3135





3 Megapixel color and 1.3 Megapixel B/W
15 fps @ 2048x1536, 32 fps @ 1280X1024
0.02 lux @ F1.4
1/2” CMOS Sensors
H.264 (MPEG 4, Part 10)
On-camera motion detection
12V DC, 24V AC, POE
Power consumption: 4 Watts max

AV3125IR
3 Megapixel IP Bullet Camera
21 fps @ 2048(H)x1536 (V)
Integrated 4.5-10mm Megapixel Varifocal Lens
Color mode: 0,3 lux
1/2,5” CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
48 IR LEDS
IP66 housing with heater and blower
External lens adjustment (Plug-n-play) and Easily adjustable 3-axis bracket

http://www.arecontvision.com





ZN-PT304L
mdc36
Live Video and Audio Monitoring via Internet Explorer
4x Digital Zoom
MPEG-4 Video Compression (Simple Profile)
Compact Size with Stylish Design
Easy to Install and Configure
Optimized Synchronization of Audio and Video
Intelligent Motion Detection
Superior Low Light Performance
Excellent Image Quality with Up to 30 Frames Per Second in Full VGA resolution
Free-bundled 16-channel recording software included
Built-in Microphone


MP3A



3 Megapixel IP Camera
15 fps @ 2048(H)x1536 (V)
0.2 lux @ F1.4
1/2” CMOS Sensor
Motion JPEG
DC Iris
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max

http://www.cbceurope.com/



WV-SF438

360-degree Network Camera
Wide range of image modes
Built-in Image and Distortion Correction
High Resolution (1080p Full HD images to 30fps)
Super Dynamic Function & Face Detection
2-area VIQS (Variable Image Quality on Specified Area)
Smooth PTZ operation without mechanical action
Smooth PTZ operation without mechanical action
Two-way audio
Double Panorama Mode, Panorama Mode, Quad PTZ Mode, Single PTZ Mode, Fisheye Mode, 4 Stream Mode
Can be installed on ceilings or walls


WV-SW598

Super Dynamic Weather Resistant Full HD PTZ Dome Network Camera featuring 30x zoom
High Resolution (1080p Full HD images up to 30fps)
90x extra optical zoom at VGA resolution with 12x digital zoom enabling 1080x zoom.
Super Dynamic 128x wider dynamic range
Face Super Dynamic technology ensures clear face image.
Advanced auto tracking
Rain-wash coating / Dehumidifier
360 degrees endless Panning
Operating Temperature –50 °C ~ +55 °C
24V AC, Power over Ethernet Plus (PoE+) - IEEE 802.3at

http://security.panasonic.com/





SNC-DH280





Full HD Network Vandal Resistant Day/Night Minidome Camera with View-DR Technology and IR Illuminator
1/3" Exmor HD CMOS image sensor with
mechanical IRC filter
CS-mount vari focal zoom lens f=3.1 to 8.9 mm, easy focus function - automatic adjustment of image focusing that simplifies installation
Horizontal resolution 600 TV lines
View-DR enhanced wide Dynamic range technology, XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H.264/MPEG-4/JPEG: 30 fps (1920 x 1080)
Number of clients: 10
Clearly see objects in the dark up to 15 m away with IR Illuminators, which allow the camera to operate in 0 lx lighting conditions
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
Triple-encoding Capability
DEPA Advanced analytics
Built-in heater for use in cold
IP66 Rating
Power consumption 23 W max.
Power requirements AC 24 V/DC 12 V/PoE
IR Illuminator: (Wave Length: 850nm (Typical), IR LED: 21pcs)
Operating temperature -30°C to +50°C (with built in heater)
ONVIF conformance


SNC-CH280





Full HD Network Vandal Resistant Day/Night Minidome Camera with View-DR Technology and IR Illuminator
1/3" Exmor HD CMOS image sensor with
mechanical IRC filter
CS-mount vari focal zoom lens f=3.1 to 8.9 mm, easy focus function - automatic adjustment of image focusing that simplifies installation
Horizontal resolution 600 TV lines
View-DR enhanced wide Dynamic range technology, XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H.264/MPEG-4/JPEG: 30 fps (1920 x 1080)
Number of clients: 10
Clearly see objects in the dark up to 15 m away with IR Illuminators, which allow the camera to operate in 0 lx lighting conditions
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
Triple-encoding Capability
DEPA Advanced analytics
Built-in heater for use in cold
IP66 Rating
Power consumption 23 W max.
Power requirements AC 24 V/DC 12 V/PoE
IR Illuminator: (Wave Length: 850nm (Typical), IR LED: 21pcs)
Operating temperature -30°C to +50°C
ONVIF conformance

http://www.sonybiz.net





SNC-RZ25P





Pan/Tilt Zoom Network Day/Night IP Camera
1/4-type CCD with Exwave HAD™ technology
Focal length f = 4.1mm to 73.8mm; 18X zoom ratio
Horizontal resolution 460 TV lines
MPEG-4/JPEG - 25fps (320x240), 15fps (640 x 480)
Number of clients: 10 (MPEG4), 20 (JPEG)
Min. illumination: 0.7lx (50IRE, F1.4, AGC ON)
Pan angle -170 to +170 degrees
Analogue Composite Video Output
Bi-directional Audio
Dual-encoding Capability
Compact Flash™ (CF) Type Card Slot/Wireless Capability
Power consumption 17 W max.
Power requirements DC 12 V or AC 24V

SNC-CS10





High-quality and affordable network-based camera
1/4-type Progressive Scan CCD
400 TV lines
Maximum frame rate JPEG : 18 fps / MPEG4 : 15 fps (640 x 480), 30 fps (370 x 240)
Number of clients JPEG: 20, MPEG-4: 10
Min. illumination 0.14 lx (F1.0, AGC ON, 30 IRE, Shutter Speed 1/4)
Analogue Composite Video Output
Power consumption 5.4 W max.
Power requirements AC 24 V/DC 12 V
Motion Detection, Pre-/post-alarm recording
Exposure control Auto Iris Lens/Manual Iris Lens

http://www.sonybiz.net










Copyright © GSC Ltd
All rights reserved
info@gsc.ge
+995 32 2 432-432
