CCTV / Signal Transmission    about us     portfolio   service   contact   news   PFM800 Passive HDCVI 1 channel passive HDCVI Balun Transmission Distance: 720P: 400M (max); 1080P: 250M (max) Category Type: UTP CAT 5E/6 (R＜10Ω/100M) Compatible Format: HDCVI Resolution: 720P/1080P Anti-interference ＞60db Coaxial Cable Connector 2KV(common-code) Per:IEC61000-4-5 UTP Cable Connector 2KV(different-code),4KV(common-code),Per:IEC61000-4-5 MTBF ＞10000H Operating Temperature -10~55℃ Dimension(L*W*H): 53mm*20mm*17mm PFM801 Passive HDCVI 1 channel passive HDCVI Balun With Power Transmission Distance: 720P: 400M (max); 1080P: 250M (max) Category Type: UTP CAT 5E/6 Compatible Format: HDCVI Resolution: 720P/1080P Anti-interference ＞60db Power supply: Input voltage DC24-36V, can provide DC12V8W(max) power supply to remote cameras. UTP Cable Connector 2KV(different-code),4KV(common-code),Per:IEC61000-4-5 MTBF ＞10000H Operating Temperature -10~55℃ Dimension(L*W*H): 72.6mm*42.5mm*24.5mm   http://www.dahuasecurity.com PFM809 Passive HDCVI 16 channel passive HDCVI Balun Transmission Distance: 720P: 400M (max); 1080P: 250M (max) Category Type: UTP CAT 5E/6 Compatible Format: HDCVI Resolution: 720P/1080P Anti-interference ＞60db Coaxial Cable Connector 2KV(common-code) Per:IEC61000-4-5 UTP Cable Connector 2KV(different-code),4KV(common-code),Per:IEC61000-4-5 MTBF ＞10000H Operating Temperature -10~55℃ Dimension(L*W*H): 430mm*100mm*44.5mm(1U) PFM700 HDMI Extender Power supply: Input voltage DC5V. Transmission effect: Real-time transmission HDMI video signal, no delay, strong anti-interference. Transmission distance: HDMI transmission distance 60M (max)  Main functions: Use single UTP (CAT-5E and CAT-6) transmit 1-ch HDMI video signal: support HDMI 1.3. Protection and anti-interference: Excellent anti-thunder, anti-static and anti-interference capabilities. Appearance structure: No need to install driver program and set network parameters, easy to use and convenient to install. Resolution 1080P/1080I/720P/576P/576I/480P/480I Operating Temperature 0~55℃ Dimension(L*W*H): 88mm×64mm×25 mm   http://www.dahuasecurity.com PFO2410T/R HDCVI Optical Transceiver 4 channel transmission Support HDCVI video format 720p/25、720p/30、720p/50、720p/60、1080p/25、1080p/30 FC（Single-mode fiber）、4*BNC、1*RS485 Transmission Distance 0-20km UPnP, easy installation Metal plate is used for the structure, fully enclosed dustproof design Power:DC12V, Power Consumption: <6W Operating Temperature ﹣40℃～70℃ Dimension(L*W*H): 100mm×150mm×30mm, DIN rail PFO2910T/R HDCVI Optical Transceiver 16 channel transmission Support HDCVI video format 720p/25、720p/30、720p/50、720p/60、1080p/25、1080p/30 SFP+（Single-mode fiber）、16*BNC、2*RS485 Transmission Distance 0-20km UPnP, easy installation Metal plate is used for the structure, fully enclosed dustproof design Power:DC12V, Power Consumption: <24W Operating Temperature ﹣40℃～70℃ Dimension(L*W*H): 440mm×300mm×43.65mm, Rack-mounted   http://www.dahuasecurity.com LLT201A&C Passive 1 Channel passive video transceiver. Receiving and transmitting video signals over UTP cable without using the power supply.                   LLT213B&C Passive 1 Channel passive transceiver. Receiving and transmitting video/audio/power over UTP cable.                     http://www.lsvt.com.cn LLT204 Passive 4 Channel passive video balun.                   LLT216 Passive 16 Channel passive video balun.                     http://www.lsvt.com.cn LLT-301 Series (T/R) Active 1 Channel active video transceiver. This device is capable of receiving and transmitting video signal over UTP cable.                   LLT-302 Series (T/R) Active 1 Channel active video and audio, 2 channels data or power transceiver. This device is capable of receiving and transmitting video/audio/power/PTZ signal over UTP cable.                     http://www.lsvt.com.cn LLT-351 Series (T/R) Active Video transmission via UPT CAT5 cable.Outstanding interference rejection/transient protection.Enables cost-effective.High quality image.                   LLT-401 Series (T/R) Active 4 Channels active video transceiver. This device is capable of receiving and transmitting videos signal over UTP cable.                     http://www.lsvt.com.cn LLT-410 Series Active 4 Channels active video/audio/power receiver. This device is capable of receiving video, audio and power DC 12V over UTP cable.                   LLT-1610R Active 16 Channels active video receiver. This device is capable of receiving video signal over UTP cable.                     http://www.lsvt.com.cn Copyright © GSC Ltd All rights reserved info@gsc.ge +995 32 2 432-432
