Compact design, focal length adjusted manually Manually operated iris
T2Z3514CS-2
Format (") 1/3
Mount CS
Focal Length (mm) 3.5-8
Aperture (F) 1.4-16C
Angle of View (HOR)° 77.6-35.4
M.O.D. (m) 0.4
Effective Aperture Front(φMxP=) 16.6
Rear (φMxP=) 9.0
Front Filter Thread (φMxP=) -
Dimensions φ34×43.5
Weight (g) 38
Compact design, focal length adjusted manually
TG2Z3514FCS-2
Format (") 1/3
Mount CS
Focal Length (mm) 3.5-8
Aperture (F) 1.4-360C
Angle of View (HOR)° 77.6-35.4
M.O.D. (m) 0.4
Effective Aperture Front(φMxP=) 16.6
Rear (φMxP=) 9.0
Front Filter Thread (φMxP=) -
Dimensions φ33.5×42.6×43.5
Weight (g) 48

http://www.cbc-de.com



Compact design, focal length adjusted manuallyAspherical lens which greatly improves the image quality and makes the design compactLens optmized for both visible and new IR spectrum which eliminates focus shift with Day&Night camerasLarge aperture that transmits more light
TG3Z2910FCS IR
Format (") 1/3
Mount CS
Focal Length (mm) 2.9-8.2
Max. Aperture Ratio 1:1.0
Angle of View (HOR)°

98.3-35.2
M.O.D. (m) 0.5
Effective Aperture Front(φMxP=) 18.8
Rear (φMxP=) 9.0
Front Filter Thread (φMxP=) -
Dimensions φ33.5×46.6×44.3
Weight (g) 50
Compact design, focal length adjusted manually Aspherical lens which greatly improves the image quality and makes the design compact Lens optmized for both visible and new IR spectrum which eliminates focus shift with Day&Night cameras
TG4Z2813FCS IR
Format (") 1/3
Mount CS
Focal Length (mm) 2.8-12
Aperture (F) 1.3-360C
Angle of View (HOR)° 98.2-23.8
M.O.D. (m) 0.3
Effective Aperture Front(φMxP=) 22.0
Rear (φMxP=) 8.8
Front Filter Thread (φMxP=) -
Dimensions φ37.5×48×56
Weight (g) 69

http://www.cbc-de.com



Compact design, focal length adjusted manually Manually operated iris Aspherical lens which greatly improves the image quality and makes the design compact
T10Z0513CS-2
Format (") 1/3
Mount CS
Focal Length (mm) 5-50
Aperture (F) 1.3-16C
Angle of View (HOR)° 51.8-5.6
M.O.D. (m) 0.8
Effective Aperture Front(φMxP=) 29.5
Rear (φMxP=) 8.7
Front Filter Thread (φMxP=) 37.5×0.5
Dimensions φ47×57.7
Weight (g) 125
Compact design, focal length adjusted manually
TG10Z0513FCS-2
Format (") 1/3
Mount CS
Focal Length (mm) 5-50
Aperture (F) 1.3-360C
Angle of View (HOR)° 51.8-5.6
M.O.D. (m) 0.8
Effective Aperture Front(φMxP=) 29.5
Rear (φMxP=) 8.7
Front Filter Thread (φMxP=) 37.5×0.5
Dimensions φ41.7×57.5×57.7
Weight (g)

125

http://www.cbc-de.com
